Features/Options

Aspen AP138 Features and Options

Beautiful and rugged, Raynor Aspen AP138 steel residential garage doors have the following features and options:

WeatherLock™ Section Joints: Raynor’s proprietary WeatherLock section joint has a continuous thermal break and air seal between steel sections. This modified tongue-in-groove joint provides exceptional strength, while effectively locking out both air and water infiltration into the garage’s interior.
NeuFoam™ Polyurethane Insulation: State-of-the-art NeuFoam polyurethane insulation is blown between the Aspen AP138 door’s steel skins and expands to fill 100% of the door’s interior space.
Hot-dipped Galvanized Steel Track: All Raynor custom-fit tracks are constructed from heavy-gauge steel for maximum stability and long life. Made specifically to order, our track is adjustable so your Aspen AP138 garage door always fits perfectly against your door opening, preventing energy loss.
EnduraCote™: Raynor’s optional EnduraCote system includes a white powder coated track, end stiles and hinges, black powder coated springs, and torsion bar.
Aspen Elements™: A collection of high-definition, digitally printed woodtone styles that embody the elemental allure of nature, blending rich grains and authentic textures to capture the essence of natural wood. Utilizing modern technology, these designs harmonize tradition with innovation, making a bold statement of style and refinement.
DASMA TPV Program: The DASMA Thermal Performance Verification Program is a voluntary program to certify and verify the thermal performance ratings of sectional door products using third-party testing and inspection. The U-Factor on this model is verified through the DASMA TPV Program.
Commercial Aspen AP138C Available: Aspen AP138 is also available in commercial sizes, up to 16’ high, and comes with our Raynor commercial hardware.

Colors

Pick Your Garage Door Color

Start creating a beautiful, customized Raynor Aspen AP138 garage door design that fits your style by selecting from one of our many color options. Deep, distinct embossing creates a sharp and detailed-looking door front. Classic, or contemporary, Raynor garage doors look high definition.

Solid Color Options


White	Almond	Desert Tan	Sandstone	Bronze	Brown

Charcoal*	Iron Ore	Slate	Black

*Features the high performance PVDF coating (TRINAR® or equivalent) paint process that provides extended UV protection against fading.

Aspen Elements™ Options


Cocoa Hickory	Honey Cedar	Cocoa Hickory	Honey Cedar

Optional Post Paint Process*

Raynor’s ColorWave™ features Sherwin-Williams® next-generation post paint system for your garage door. With 1,500 colors to choose from, home and business owners can couple this elite paint system with state-of-the-art Raynor manufacturing to craft the perfect look for their home or project.

* Not all colors are available in solar reflective paint, colors that are not available as solar reflective cannot be used on polyurethane doors.

>>Not all colors are available on all embossments. Contact your local Raynor Authorized Dealer for a complete listing of colors available by embossment.

>>Colors displayed on monitors, mobile devices, and printed materials will vary from the actual steel color. Contact your local Raynor Authorized Dealer for color samples.

>>Black and charcoal colored steel doors come standard with a Cool Chemistry™ paint finish to protect from extreme heat. For environments where extreme heat and sunlight exposures are constant, black and charcoal colors are not recommended.

Panels

Pick Your Garage Door Panel

Raynor Aspen AP138 offers seven distinctly different panel options to help give your home a custom and unique look.


Raised Colonial	Raised Ranch	Flush	Recessed Colonial Grooved	Recessed Ranch Grooved	Plank

Mixed Panel Raised or Recessed	Recessed Ranch	Carriage House Panel Spacing Options

Hardware

Pick Your Decorative Hardware

Add character to your Raynor Aspen AP138 steel garage door with attractive optional decorative face hardware. The black matte powder coated magnetic straps and handles are designed to appear hand-forged, adding a historically accurate dimensional quality to your door.

Our lightweight and durable magnetic decorative hardware instantly add character and charm to any steel garage door! These accessories come with an authentic wrought iron look and are easy to install! Mount your hardware quickly and easily as many times as you need to without the worry of leaving holes from traditional drilling installations. Put the finishing touches on your new Raynor Aspen AP138 garage door, today!

Decorative Hardware Options

Handles

Straps

Plastic Decorative Hardware Kits

Windows

Decorative Windows

Our beautiful window designs put the finishing touch on your Raynor Aspen AP138 steel garage door. Choose from clear, obscure, or satin glass, standard or insulated.

Glass Options

*Black satin available on insulated units only

Snap-In Styles

Snap-in window designs add charm to any home. Choose from a variety of styles.

Ranch Snap-In Style Options


Ranch	Waterton Ranch	Cascade Ranch

Stockbridge Ranch	Arched Stockbridge Ranch	Stockton Ranch

Praire Ranch	Berkshire	Breckenridge

Colonial Snap-In Style Options


Colonial	Waterton Colonial	Cascade Colonial

Prairie Colonial	Arched Stockton Ranch	Stockton Colonial

Details/Literature

Product Details

Series	Aspen steel garage doors
Level	Standard
Max Door Width	20’2” (20’2” in commercial sizes)
Max Door Height	10’0” (16’0” in commercial sizes)
Construction	3-Layer (Steel, Insulation, Steel)
Section Thickness	1-3/8″
Material	Hot-Dipped Galvanized Steel; 26-gauge
Surface Texture	Woodgrain
Insulation	NeuFoam™ Polyurethane
Tested U-Factor	0.20
Calculated R-Value	13.0
Thermal Break	Yes, full length
Section Joint Seal	Yes, full length
Section Joint Type	Raynor WeatherLock, Tongue-in-Groove
Door Designs	Raised Colonial, Raised Ranch, Recessed Colonial Grooved, Recessed Ranch Grooved, Recessed Ranch, Mixed Panel Raised or Recessed, Flush, Plank
Colors	White, Almond, Desert Tan, Sandstone, Bronze, Brown, Charcoal, Iron Ore, Slate, Black, Dual Design Cocoa Hickory, Dual Design Honey Cedar, Plank Design Cocoa Hickory, Plank Design Honey Cedar, ColorWave™
Glass	Clear, Satin, Black Satin, Dark Tinted, Obscure
Decorative Windows	Various snap-in designs in colonial or ranch size
Track & Door Hardware	Galvanized or Powdercoat available
Wind Load Systems	FBC: Yes TDI: Yes HVHZ: No
Single Family Residential Warranty: Limitations and Exclusions May Apply	Sections: Limited Lifetime Galvanized Track & Hardware: 6 years Powdercoated Track & Hardware: Limited Lifetime Springs: 3 years Powdercoated Springs: Limited Lifetime Windows: 3 years Climate Seal: 1 year Windload Doors: 3 years ColorWave™: 5 years

Product Literature

Specs/Drawings

Specifications

Select a link below to download Raynor Commercial AP138C specifications.

	Word	PDF
AP138C Product Specs	DOCX	PDF
Full Sectional Product Line Specs	DOCX	PDF

Warranty

Aspen AP138 Garage Door Warranty

Door Sections:

Single Family Residential: Raynor® warrants the door sections against defects in material and workmanship, and deterioration due to rust (exterior only) for as long as the original purchaser owns the home. Raynor also warrants the door sections against delamination of the polyurethane foam insulation from the steel skins for as long as the original purchaser owns the home. Window components are warranted against defects in material and workmanship for three (3) years from date of delivery to the original purchaser. Climate seal is warranted against defects in material and workmanship for one (1) year from date of delivery to the original purchaser.

All Other Residential (including installation on rental properties, homes owned by common condominiums associations or similar organizations): Raynor® warrants the door sections against defects in material and workmanship, and deterioration due to rust (exterior only) for three (3) years from date of delivery to the original purchaser. Raynor also warrants the door sections against delamination of the polyurethane foam insulation from the steel skins for three (3) years from date of delivery to the original purchaser. Window components are warranted against defects in material and workmanship for three (3) years from date of delivery to the original purchaser. Climate seal is warranted against defects in material and workmanship for (1) year from date of delivery to the original purchaser.

Hardware and Springs:

Single Family Residential: EnduraCote™ Hardware: Raynor® warrants all hardware and spring components against defects in material and workmanship for as long as the original purchaser owns the home.

Galvanized Hardware: Raynor® warrants all hardware components against defects in material and workmanship for six (6) years and springs for three (3) years from date of delivery to the original purchaser.

Raynor Wind Load systems are warranted against defects in material and workmanship for three (3) years from date of delivery to the original purchaser.

All Other Residential (including installation on rental properties, homes owned by common condominiums associations or similar organizations):
EnduraCote™ Hardware: Raynor® warrants all hardware and spring components against defects in material and workmanship for three (3) years from date of delivery to the original purchaser.

Galvanized Hardware: Raynor® warrants all hardware and spring components against defects in material and workmanship for one (1) year from date of delivery to the original purchaser.

ColorWave™ Paint System
Raynor provides a five-year warranty for the ColorWave Paint System (exterior only) against chipping, cracking, and peeling (loss of adhesion) from the date of delivery to the original purchaser. This warranty covers defects in materials and workmanship under normal use and proper maintenance. Please note that fading, as well as chipping, cracking, or peeling caused by dents or scratches, are not included in this coverage. Additionally, for doors made with polyurethane insulation, a solar reflective paint formulation is required to maintain the warranty. Ordering a color that does not meet this requirement will void the warranty for the ColorWave Paint System. Field applied paint is not covered by this warranty. This warranty applies only to the original purchaser and may be subject to inspection before approval of any claim.

Warranty Limitations and Exclusions:

Under the terms of this limited warranty, for any door components that are found to be defective upon inspection by authorized Raynor personnel, Raynor will, at its option, repair or replace the defective door components. Labor charges for the installation or repairs shall be the responsibility of the consumer and must be performed by an authorized Raynor dealer.

This limited warranty extends only to the original purchaser, provided the door is installed in his/her place of residence. This limited warranty is not transferable. This limited warranty applies to residential property only and is not valid on commercial applications or commercial use from a private residence.

This limited warranty does not apply to automated parking control systems for multiple-tenant parking applications.

This limited warranty does not apply to black, charcoal, slate, and iron ore steel colors used on Raynor Aspen Series, Commercial Aspen Series, Country Manor, and RockCreeke doors when installed in areas experiencing extreme heat for prolonged periods of time. The result of these environmental conditions can elicit a failure of the polyurethane core of the door. The warranty also excludes doors which have been field painted where the paint does not include a solar reflective additive.

This limited warranty does not apply to any damage or deterioration to the door caused by abuse, negligence, missing components, accidents, use of pressure washers, dents or scratches. Shavings from trolley rails not properly removed and cleaned from the exterior door surface causing rust are not covered by this warranty. Failure to provide proper maintenance voids this limited warranty. Field applied paint failure is not covered by this limited warranty. Refer to the Care and Maintenance Instructions and Painting Instructions.

This limited warranty does not apply to damage caused by fire, an act of God, accident, vandalism or graffiti. Damage or deterioration caused by saltwater coastal areas (within two miles), hazardous or corrosive chemicals and fumes including, but not limited to, alkaline, acids, muriatic acids, road salt or salt environments, harsh cleaning agents, and fertilizers is not covered by this limited warranty.

This limited warranty does not apply to building damage caused by moisture infiltration through or around the door. A garage door system is water resistant, but not waterproof. When a garage door system is properly assembled, installed, and maintained the risk of significant water infiltration is low.

Raynor will not be responsible for paint rub on installed doors in any openings. Raynor shall not be liable for any consequential or incidental damages.

ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY EXPRESSLY EXCLUDED.

Some states do not allow the exclusion or limitation of consequential or incidental damages, so the above limitation or exclusion may not apply to you.

Claims for defects in material and workmanship covered by this warranty shall be made in writing with proof of purchase and photographs of the product in question to the dealer from whom the product was purchased or call Raynor at 1-800-4-RAYNOR within the warranty period. Raynor may choose to have the product returned for inspection.

This limited warranty gives you specific legal rights. You may also have other rights, which vary from state to state.

Register Your Warranty

Your registration enforces your warranty coverage and will keep you up to date on product information and offers. Register your Raynor Aspen AP138 warranty here.
