Model 432

Sectional steel door model 432 offer a 2" (51 mm) panel thickness, a nominal 24-gauge ribbed galvanized steel exterior, and a poly-bonded back cover. Polystyrene insulation provides an R-value of 7.35. A variety of options makes this door an economical solution for applications requiring a medium-duty insulated steel door.

contact us about this product

Ideal Applications Include

  • Public Facilities
  • Warehouse Solutions
  • Manufacturing
  • Security
  • Automotive

more Model 432 details

Overview

Construction

Product Specifications
Standard Max Width 20'2" (6147 mm)
Standard Max Height 16'1" (4902 mm)
Nominal thickness 2" (51 mm)
Exterior steel 26-gauge galvanized steel
Back cover Poly-bonded laminate
Insulation Expanded polystyrene
R-value 7.35 (1.29 W/Msq)
Exterior surface Ribbed
Wind Load Compliance FBC approved wind load options available
End stiles 16-gauge steel
Center stiles 16-gauge steel
Standard mounting Angle mount
Standard track 2" (51 mm)
Standard springs 10,000 cycle
Weather Stripping Standard on bottom
Operation Manual pull rope or electric operator
Finish White or Industrial Brown baked-on polyester
Lock Interior mounted slide lock



Warranty

  • 1-year limited

Options

Panel Options

Ribbed Panel

Color

White

Industrial Brown

Actual door color may vary slightly from the digital representation above.

Enhancements

  • Chain Hoist or Electric Operator is recommended for doors above 10’ tall or more than 400 pounds
  • 26-gauge galvanized steel back cover
  • High impact polystyrene (HIPS) back cover
  • Bottom sensing edge
  • Full sash section with 1/8" (3 mm) DSB, insulated; 1/8" (3 mm) and 1/4" (6 mm) acrylic
  • Individual lites with 1/2" (13 mm) DSB
  • 3" (76 mm) track
  • Higher-cycle springs in 25k, 50k, 75k, 100k cycles
  • Exhaust ports
  • Jamb weather seals
  • Bottom strips; including: looped PVC weatherstrips, flexible PVC astragal weatherstrips, and double-contact weatherstrips
  • Reinforcing struts of roll-formed, galvanized steel
  • Movable center posts for 2" (51 mm) or 3" (76 mm) tracks that roll away, with automatic safety catches that prevent door closure when posts are removed
  • Tumbler keyed lock
  • Window Glazing Options
  • Warehouse Package – Quick install system available
  • Impact Section Available
