Model 880

Model 880 ADV-Xtreme flexible bottom interior high speed fabric door can satisfy commercial applications where safety, reliability, and end-user-focused features are of the utmost importance. Equipped with a flexible bottom, the new Model 880 ADV-Xtreme reduces damage in case of accidental collisions, unlike traditional models which feature a rigid steel bottom. Thanks to its breakaway design, robust operating and easy troubleshooting have been made possible.

Ideal Applications Include:

  • Healthcare Facilities
  • Manufacturing & Warehouse
  • Warehouse Facilities
  • Distribution
  • Pharmaceutical
  • Food & Beverage

more Model 880 details

Features

Standard Construction Model 880
Openings Interior / Interior
Max. Width 12'
Max. Height 12'
Max. Opening Speed up to 70” per second
Max. Closing Speed up to 40” per second
Breakaway Self-Reset Yes
Curtain Material 2 layers of light PVC-coated polyester with 1 layer of polyester weave
Curtain Lock Yes
Operation Direct drive motor and gearbox system with field changeable universal handing and door stop safety device
Control Panel Variable frequency drive, self-diagnostic, programmable service reminders,
pad-lockable fused disconnect NEMA 4X rated, cULus listed
Supply Voltages** 120V AC 1 PH
208V AC 1 PH
220V AC 1 PH
208V AC 3 PH
230V AC 3 PH
460V AC 3 PH
575V AC 3 PH
Bottom seal Flexible bottom edge with detachable seal
Safety Features Obstruction Safety Detection
Reversing Sensing Edge
Wind Load* up to 3.0 psf

*Only internally approved wind load reinforcement is available to withstand conditions in wind prone areas. Wind load is the ultimate pressure tested at a door width of 12'
**Single phase available for up to 10'x10' doors.
(†Requires stand-alone mounted transformer)

Benefits

Safety Focused

  • Flexible bottom diminishes the potential for injury
  • Monitored wireless reversing safety edge immediately stops and reverses the door when an obstacle is detected
  • Two sets of safety obstruction sensors

High Performance, Low Maintenance Design

  • Strutless design lowers the operational noise of the door for quiet and smooth operation
  • Springless design requires minimal interruption for maintenance
  • Direct-mounted gear drive minimizes wear and tear
  • Variable frequency drive eliminates sudden jolts from door start and stop operation

Field Repairable

  • Patented breakaway system design with impact detection and push button self-repair
  • Patented curtain lock allows for easy field repairs
  • Detachable bottom seal in safety yellow for easy replacement and troubleshooting
  • Hinged guides provide easy access for maintenance

Installer Friendly

  • Pre-assembled sub-assemblies for easier installation
  • Plug-ang-play wiring reduces the need for a licensed electrician

Warranty

  • 5-Year Limited Warranty on drive motor and gearbox
  • 1-Year Limited on all other components

Enhancements

Safety Focused

Actuation Options

  • Push button
  • Motion detector
  • Radio control
  • Key switch
  • Pull switch
  • Loop detector
  • Treadle switch


Signal Device Options

  • Red/green LED warning light
  • Horn/strobe combination
  • Rotating warning light


Programmable LED Lighting Package

  • 3' tall light bar with red, yellow, and green lights

Design Options

  • 20" high vision panels spaced evenly across the width of the door
  • Light curtain – front or rear mounted; available in 3' and 6' models.

Colors

Curtain Color Options

red fabric 880 881 882 887 blue fabric 880-881 882 887 gray fabric 880 881 882 887 white fabric 880 881 882 887
Red Blue Gray White

Guides/Brackets/Struts/Bottom Bar Colors

safety yellow 887
Yellow

RAL Powder Coat*

Approximately 200 powder coat options are available to complement the exterior colors of a building.

Custom RAL garage door paint colors

*Online color swatches are only digital reproductions of actual standards and will vary in appearance due to differences in monitor and video card output. These digital representations should not be used to finalize color selection(s). Actual physical representation may vary slightly in color.
