more Model 883 details

Features

Standard Construction	Model 883
Max. Width	20'
Max. Height	20'
Max. Opening Speed	up to 65” per second
Max. Closing Speed	up to 40” per second
Bottom Bar Breakaway	Yes
Wind Struts	Metal struts and roller wind locks
Curtain Material	3 layers of PVC-coated polyester with 2 layers of polyester weave
Header Braces	Multiple braces across entire width strengthen and combat sagging
Hood	Protection from debris and moisture
Operation	Direct-drive motor and gearbox system with field changeable universal handing and door stop safety device
Control Panel	Variable frequency drive, self-diagnostic, programmable service reminders, padlockable fused disconnect NEMA 4X rated, cULus listed
Supply Voltages**	208V AC 1 PH^† 220V AC 1 PH 208V AC 3 PH^† 230V AC 3 PH 460V AC 3 PH 575V AC 3 PH^†
Safety Features	Obstruction Safety Detection Reversing Sensing Edge
Wind Load*	up to 19.5 psf

*Wind load is the ultimate pressure tested at a door width of 20'
**Single phase available u to 10"x10".
(†Requires stand-alone mounted transformer)

Benefits

High Performance, Low Maintenance Design

Standard hood blocks moisture and debris from impeding door operation
Springless design requires minimal interruption for maintenance
Direct-mounted gear drive minimizes wear and tear
Variable frequency drive eliminates sudden jolts from door start and stop operation
Patented breakaway system design with impact detection and push button self-repair

Rugged Fabric Construction

Ideal for exterior applications

Field Repairable

Hinged guides provide easy access for maintenance

Installer Friendly

Pre-assembled sub-assemblies for easier installation
Plug and play wiring reduces the need for a licensed electrician

Excellent Wind Load Protection

Patented roller windlocks on struts
Bottom windlocks for pressure protection

Warranty

5 Year Limited Warranty on drive motor and gearbox
1 Year Limited Warranty on all other components

Enhancements

Options

Safety Focused

Actuation Options

Push button
Motion detector
Radio control
Key switch
Pull switch
Loop detector
Treadle switch
Wireless

Signal Device Options

Red/Green LED warning light
Horn/Strobe combination
Rotating warning light

Programmable LED Lighting Package

3' tall light bar with red, yellow, and green lights

Light curtain

front or rear mounted; available in 3' and 6' models.

Design Options

Finish Options

Powder Coat
Hardened Powder Coat*
G-90 Galvanized
Anodized Aluminum

Colors

Curtain Color Options


Red	Blue	Gray	Orange

Guides/Brackets/Struts/Bottom Bar Colors


Safety Yellow	Black

Standard color for guides, brackets, struts and bottom bar is yellow.

RAL Powder Coat*

Approximately 200 powder coat options are available to complement the exterior colors of a building.

*Online color swatches are only digital reproductions of actual standards and will vary in appearance due to differences in monitor and video card output. These digital representations should not be used to finalize color selection(s). Actual physical representation may vary slightly in color.
