more Model 885 details

Features

Standard Construction	Model 885
Openings	Exterior
Max. Width	30'
Max. Height	30'
Max. Opening Speed	up to 50” per second
Max. Closing Speed	up to 40” per second
Breakaway Self-Reset	Yes
Curtain Material	5 layers of NBR rubber with 4 layers of polyester weave
Operation	Direct drive motor and gearbox system with field changeable universal handing and door stop safety device
Control Panel	Variable frequency drive, self-diagnostic, programmable service reminders, pad-lockable fused disconnect NEMA 4X rated, cULus listed
Supply Voltages	208V AC 3 PH^† 230V AC 3 PH 460V AC 3PH 575V AC 3 PH^†
Safety Features	Obstruction Safety Detection Reversing Sensing Edge
Wind Load*	up to 27.0 psf

*Wind load is the ultimate pressure tested at door width of 19'.
(†Requires stand-alone mounted transformer)

Benefits

Rugged Construction

Multi-layered, reinforced rubber provides added strength without the weight
Ideal for harsh exterior conditions with a wind load of up to 27.0 psf
Nitrile butadiene rubber (NBR) provides resistance to petrochemicals for easy cleaning
Continuous curtain locks on both edges.

High Cycle, Low Maintenance Design

Springless design requires minimal interruption for maintenance
Patented breakaway system design with impact detection and push button self-repair
Direct-mounted gear drive minimizes wear and tear
Variable frequency drive eliminates sudden jolts from door start/stop

Installer Friendly

Pre-assembled sub-assemblies for easier installation
Plug-and-play wiring reduces the need for a licensed electrician

Warranty

5-Year Limited Warranty on drive motor and gearbox
1-Year Limited Warranty on all other components

Enhancements

Options

Safety Focused

Actuation Options

Push button
Motion detector
Radio control
Key switch
Pull switch
Loop detector
Treadle switch
Wireless

Signal Device Options

Red/Green LED warning light
Horn/Strobe combination
Rotating warning light

Programmable LED Lighting Package

3' tall light bar with red, yellow, and green lights

Light curtain

front or rear mounted; available in 3' and 6' models.

Design Options

20" high vision panels spaced evenly across the width of the door

Colors

Curtain Color Options


Black (Standard)	Blue

Guides/Brackets/Struts/Bottom


Black	Safety Yellow

Standard color for guides, brackets, struts and bottom bar is yellow.

RAL Powder Coat*

Approximately 200 powder coat options are available to complement the exterior colors of a building.

*Online color swatches are only digital reproductions of actual standards and will vary in appearance due to differences in monitor and video card output. These digital representations should not be used to finalize color selection(s). Actual physical representation may vary slightly in color.
