more Model 888 details

Features

Standard Construction	Model 888
Openings	Exterior/Interior (mount inside)
Max. Width	26'
Max. Height	21'
Max. Opening Speed	up to 80” per second
Max. Closing Speed	up to 20” per second
Curtain Material	Dual-walled aluminum
Operation	Direct drive motor and gearbox system with field changeable universal handing and door stop safety device
Control Panel	Variable frequency drive, self-diagnostic, programmable service reminders, padlockable fused disconnect NEMA 4X rated, cULus listed
Supply Voltages	230V AC 3 PH 460V AC 3 PH 575V AC 3 PH^†
Safety Features	Obstruction Safety Detection Reversing Sensing Edge
Wind Load*	up to 100.0** psf

*Wind load is the ultimate pressure tested at door width of 19'.
**Up to +50/-50 psf with optional vision panels
^†Requires stand-alone mounted transformer

Benefits

High Performance Design

Springless design for over 1 million cycles and requires minimal interruption for maintenance
Gravity drive system coupled with variable frequency drive eliminates sudden jolts from door start and stop operation
Direct-mounted gear drive minimizes wear and tear

Durable Construction

Dual-walled, solid aluminum curtain for security and privacy
Steel headplate utilizes high strength, durable rollers to prevent metal curtain contact and provides smooth operation

Installer Friendly

Fully-assembled curtain arrives pre-wrapped in headplate and trusses, ready for installation
Completely hinged guide for easy access and maintenance
Pre-wired motor connection and plug and play accessories reduces need for licensed electrician

Safety Focused

Patented integrated curtain monitoring device ensures the door has a redundant system to monitor the position of the door
Safety light curtain minimizes contact with objects in the doorway
Monitored wireless reversing edge

Warranty

5 Year Limited Warranty

Enhancements

Safety Focused

Photo Eyes

Actuation Options

Push button
Motion detector
Radio control
Key switch
Pull switch
Loop detector
Treadle switch
Wireless

Signal Device Options

Red/Green LED warning light
Horn/Strobe combination
Rotating warning light

Programmable LED Lighting Package

3' tall light bar with red, yellow, and green lights

Design Solutions

Florida Building Commission Impact Rating – Certified for Florida's High Velocity Hurricane Zone

Design Options

Square Hood

Vision Options

Perforated Slat- up to four slats with 24% open area (up to 20' wide)
Vision Slat- up to four slats for vision through the door

Slim Guide

Reduces jamb side room (size limitations may apply)

Colors

Guides/Slats/Bottom Bar

Silver Powder Coat (Standard)

Bracket/Hood Structure

Black Powder Coat (Standard)

**Silver powder coat made to mimic anodized aluminum.

RAL Powder Coat*

Approximately 200 powder coat options are available to complement the exterior colors of a building.

*Online color swatches are only digital reproductions of actual standards and will vary in appearance due to differences in monitor and video card output. These digital representations should not be used to finalize color selection(s). Actual physical representation may vary slightly in color.
