  • Rolling Fire

back to Commercial Overhead Doors garage doors

Rolling Fire

Our roll-up fire doors meet all of your compliance needs, including practical drop testing and positive crisis response. And they’re guaranteed to provide you with reliable, predictable, and repeatable functionality.

contact us about this product

more Rolling Fire details

Overview

  • Easily execute simple, expensive, and repeatable drop testing
  • Available in a variety of gauges, slate profiles, and colors
  • Fail-safe time-delayed release options
  • Smoke detectors, audio warning systems, and visual warning systems



Model # 7301 7302 7366 7400 7401
Slat Flat Flat Flat Curved Flat
Material Steel Steel Stainless Steel Steel
Insulation Type No Insulation Mineral Wool No Insulation No Insulation No Insulation
Max. Height 24'0" 20'4" 24'0" 24'0" 24'0"
Max. Width 24'0" 24'0" 13'4" 24'0" 24'0"
R-Value -- 4.2 -- -- --



Fire Ratings by Model

Fire Ratings 7301 7302 7366 7400 7401
3/4 Hr. ✔︎ ✔︎ ✔︎ ✔︎ ✔︎
1 - 1/2 Hr. ✔︎ ✔︎ ✔︎ ✔︎ ✔︎
3 Hr. ✔︎ ✔︎ ✔︎ ✔︎ ✔︎
4 Hr. -- -- -- ✔︎ ✔︎



Ideal Applications:

  • Cafeterias
  • Churhes
  • Schools

Design Options

Colors

White Gray Galvanized Tan Brown Stainless RAL Powder Coat



Colors Available Per Model
Model # 7301 7302 7366 7400 7401
White ✔︎ ✔︎ -- ✔︎ ✔︎
Gray ✔︎ ✔︎ -- ✔︎ ✔︎
Galvanized ✔︎ ✔︎ -- ✔︎ ✔︎
Tan ✔︎ ✔︎ -- ✔︎ ✔︎
Brown ✔︎ ✔︎ -- ✔︎ ✔︎
Stainless -- -- ✔︎ -- --
RAL Powder Coat ✔︎ ✔︎ -- ✔︎ ✔︎

FAQs

Materials

What are C.H.I. doors made of?
  • Our doors are made from Nucor EconiqTM steel – the world’s first net-zero carbon steel. It’s 100% recyclable and made up of 65.25% recycled ferrous scrap metal.



Paint

How should I paint my door?
  • Most of our doors come painted, but if you’d like to paint an unfinished door or give a pre-painted door another coat, please read our guide for detailed instructions. The painting method varies significantly depending on the material your garage door is made from, so choose the method that matches the material.
Where can I find paint formulas for my C.H.I. door?
Can I order my C.H.I. door in a custom color?

  • Yes! We offer in-house powder coating in 188 colors. We can also color match and create custom colors – this may increase lead times and cost. Availability varies by model.



Warranty

What's the warranty for my C.H.I. door?
  • We provide a limited lifetime warranty on our doors. This varies by model. You can find more information on their warranty page.
Do I need to register my door for the warranty?

  • No, you don’t need to register your door. All the information necessary for a successful warranty claim can be found on your original purchase receipt. Claims are processed using the door code assigned to your door when it is ordered.

How do I submit a warranty claim?



Wind Load

Do you offer wind load products that meet Miami-Dade certification requirements?
  • We offer a variety of wind load products and continue to expand our offerings in this area, but we don’t currently hold Miami-Dade certifications.
