Accessories & Options
Timer Close Module
Timer close set via the LCD display from 2 seconds up to 5 minutes. Includes pre-close warning contacts, timer hold input, auxiliary open input, normally closed safety input, and T3 monitored edge input. (P/N: OPABTCX.S)
Auxiliary Output Module
Provides relay contacts at the open, close, and mid-stop limits. Contacts for 5-minute lamp, and “ADA” contacts set via LCD display to warn during opening, closing or both. (P/N: OPABIOX.S)
Edge Sensing Module
Input allows connection of a T3 monitored safety edge. When advanced timer close features are required, use the Timer Close Module. (P/N: OPABESX.S)
Friction ClutchUL 325 Approved Reversing Devices
The installation of a monitored external entrapment device is required for momentary contact close operation on all commercial door operators. Only the following devices, when purchased through Overhead Door Corporation, are UL approved for use to meet this requirement:
- Safe-T-Beam® Photocell kit with adjustable bracket P/N: 38176R.S 1
- Impact-protected Commercial Photocell Kit P/N: OPAKPE2.S
- NEMA 4X Photocells P/N: OPAKRPEN4GX.S
- Retro Reflective NEMA 4X Photocells P/N:OPRAKRPEN4X.S
- Monitored Light Curtains - 3’ P/N: OPAKMLC3.S 6’ P/N: OPAKMLC6.S
- Light curtain mounting brackets (6 total) P/N: 112809.0001.S
- MillerEdge ME/MT/CPT (DC or T3) 2-wire edge sensor. Must be used with TCM (OPABTCX.S), ESM (OPABESX.S), or Interface Module (OPAKMEIX.S).
