Energy Series

Models

*Calculated door section R-value is in accordance with DASMA TDS-163

*Tested door U-factor is in accordance with DASMA 105.

Options

Glass Panel Options

24" X 8" (3150, 3200, 3220)	24" X 12" (3150, 3200, 3220)
Full-View* (3150, 3200, 3220)	19-1/2" x 12" (3154, 3155, 3211, 3213)

*Aluminum Intellicore polyurethane full-view section available

Note: Windows available in insulated or insulated tempered glass.

Glazing Material Options

Clear Glass

Gray Tinted Glass

Bronze Tinted Glass

Mirrored Glass*

Obscure Glass

White Laminate Glass*

Frosted Glass Or Acrylic

Clear Acrylic

Gray Acrylic

White Acrylic

Clear Polycarbonate

Bronze Polycarbonate

Aluminum Panel (Color Matched)

*Mirrored and laminate not available in 1/2"

Glass thickness available in 1/8", 1/4" and 1/2". Tri-wall polycarbonate thickness available in 1/2". Low-E available on insulated glass.

Color Options

Standard White

Chocolate

Almond*

Desert Tan*

Sandtone*

Mocha Brown*

Charcoal*

Bronze*

Black*

Commercial Tan*

Gray*

Trinar® White*

Trinar® Beige*

Request Color Samples

*Available on select models.

Performance Options Available

Double-end hinge

3" track

High performance hardware features 10 gauge end hinges, heavy-duty top bracket and 3" sealed roller with 5/8" stem

Exhaust port can be cut into any type of solid sectional door. Available in select sizes.

WindCode^® reinforcement available up to W8 design pressure (DP) 52 PSF, depending on door configuration. Doors tested 50% greater than DP.

Upgrade your standard door with industrial-grade components.

25,000, 50,000 or 100,000 cycle springs available.

Features & Benefits

Specs/Drawings

Brochures

Model 3154 & 3155 Brochure Model 3150 Brochure Model 3200-3211-3213 Brochure Brochure Model 3220 Extended 8-Year Hardware Warranty

Springs & Hardware

Commercial Hardware

Commercial doors are designed with hardware to meet demanding applications of commercial building usage. All commercial doors are provided with the following hardware as standard. For additional upgraded hardware see “Options” tab.

• 14 gauge hinges
• Commercial 10 ball steel rollers with options for nylon tire rollers
• 10,000 cycle torsion springs
• Steel step plate and lift handle for easy operation
• Inside slide lock for increase security
• 19 gauge steel hinge support plates
• 18-gauge single end stiles; 16-gauge double end stiles
• Galvanized aircraft cables with 7:1 safety factory
• 2” or 3” track in a variety of configurations to meet building design requirements


Commercial Track Options

In commercial settings, space utilization and space constraints are important factors in choosing the correct hardware configuration for your application. Clopay track offerings and options enable you to make the most efficient use of available space. Options include standard lift, low head room front or rear mount, follow the roof pitch, full vertical or combination of these options.  Learn more>

Commercial Torsion Springs

Designed to counterbalance even the largest doors, commercial torsion spring assemblies can be designed for Industry standard 10,000 cycles or can be upgraded to 25,000, 50,000 or 100,000 expected life cycles. Click here for details.
