Sectional Warehouse Doors – Model 405

Our Sectional Warehouse Doors provide a highly efficient design for strength and longevity for use in demanding commercial settings. They feature full 2” thickness for ultimate strength and durability. Optional insulation consists of 1 5/16” expanded polystyrene throughout the door. Both steel and polylaminate backer choices are available to ensure these models are well-suited for a wide range of applications.

Ideal Applications Include

  • Public Facilities
  • Warehouse Solutions
  • Manufacturing

more Sectional Warehouse Doors – Model 405 details

Overview

Door Features

Model  401 402 403 404 405 406
Exterior Steel Gauge 20 Gauge 20 Gauge 24 Gauge 24 Gauge Nom. 24 Gauge Nom. 24 Gauge
Section Thickness 2" 2" 2" 2" 2" 2"
Joint Profile Tongue & Groove Tongue & Groove Tongue & Groove Tongue & Groove Tongue & Groove Tongue & Groove
Insulation   Expanded
Polystyrene
N/A Expanded
Polystyrene
N/A Expanded
Polystyrene

Interior Backer Options N/A Vinyl or Steel​ N/A Vinyl or Steel​ N/A Vinyl or Steel​
Max. Width 30'2" 30'2" 30'2" 30'2" 30'2" 30'2"
Max. Height 22'1" 22'1" 22'1" 22'1" 16'1" 16'1"
Section Sizes 19", 21", 24" 19", 21", 24" 19", 21", 24" 19", 21", 24" 19", 21", 24" 19", 21", 24"
R-value* N/A 7.64 N/A 7.64 N/A 7.64
Exterior Surfac.  e Ribbed Ribbed Ribbed Ribbed Ribbed Ribbed
Standad Spring-Cycles 10,000 10,000 10,000 10,000 10,000 10,000
Warranty 1-Year Limited 1-Year Limited 1-Year Limited 1-Year Limited 1-Year Limited 1-Year Limited

*R-Value is a measure of thermal efficiency. The higher the R-Value the greater the insulating properties of the door. Overhead Door Corporation uses a calculated door curtain R-Value for our insulated doors.

Options

Enhancements

  • Chain hoist operation
  • Motor operation​​
  • High cycle spring (25K, 50K, 100K)​
  • 3" track option
  • Solid shafts
  • Perimeter weatherseal​
  • Broken cable devices
  • Safety edges​
  • Safety photo eyes
  • Special track designs
  • Simple Install System
