  • Model 436

back to Overhead Door garage doors

Model 436

WindStorm™ Commercial Sectional Model 436 is a insulated door featuring FBC and TDI certifications for static pressures and impact with a R-value of 7.64. Constructed of nominal 24-gauge steel and designed with 4” horizontal struts to enhance door strength. ​​​

contact us about this product

Ideal Applications Include

  • Public Facilities

more Model 436 details

Overview

Construction

Product Specifications
Standard Max Width 20'2" (7341 mm)
Standard Max Height 16'1" (7924 mm)
Section thickness 2" (51 mm)
Exterior steel Nominal 24-gauge
Exterior surface Ribbed
Struts 4" horizontal strut (doors over 10'2" wide)
Interior color White
Standard springs 10,000 cycles
Standard track 2" (51 mm)
Joint profile Tongue-and-groove
Wind Load Certified to meet FBC and TDI wind load requirements

Warranty

  • 1 year limited

Options

Panel Options

  • Ribbed Panel

Color

Exterior Colors

  • white color swatch

    White

  • brown color swatch

    Brown

Glass/Windows

  • Vision Lites

  • Full-view Lites

Enhancements

  • Chain hoist operation
  • Motor operation
  • High Cycle Springs - 25k, 50k, 100k
  • 3” track option
  • Solid shafts
  • Perimeter weather seal
  • Broken cable devices
  • Safety edges
  • Safety photo eyes
  • Impact glazing 12” x 10”
  • Security locks
  • Exhaust ports
