Model 464

Model 464 frameless glass door is designed to seamlessly integrate indoor and outdoor spaces. Frameless glass panels are mounted on a rugged aluminum structure that is designed for long life. Available in five different glass finishes and five aluminum structure finishes, the aluminum full-view door can go along with the aesthetics of the building. Practically weather-resistant and low maintenance, Model 464 is ideal for commercial applications where you require an ultimate sleek and modern frameless glass door.

contact us about this product

Ideal Applications Include:

  • Restaurants
  • Auto dealerships
  • Business Interior Room Divider
  • Bars

more Model 464 details

Features

Standard Construction Model 464
Max. Width 18'2"
Max. Height 14'1"
Door Assembly Stile and rail assembly of aluminum alloy 6063-T6, 1 ³/₈" thick stiles and rails, joined with self-tapping screws
Rails Top, upper, intermediate, and bottom rails ranging from 1-5/8” to 3-1/2" wide with a minimum wall thickness of 0.062"
Stiles End stiles are 3 ½" wide, center stile 3" wide, minimum wall thickness 0.062"
Exterior Surface Smooth, Ribbed
Spring Cycles 10,000
Track Provide track as recommended by manufacturer to suit loading required and clearances available
Air Infiltration (IECC) 0.4 cfm/ft2



Benefits

Durable Design
  • Built on a rugged aluminum structure that is designed for longevity and durability
  • Glass is adhered to the front of the door using the same adhesive as on skyscrapers
  • Minimizes airflow with a vinyl seal between the section seals
  • Meets California Code of Regulation, Title 24 air infiltration requirements with a third-party tested value of less than 0.3 cfm/ft2

Warranty

  • 1-Year against defects in materials and workmanship



Enhancements

High-Performance Design

High Cycle Spring Options
  • 25,000
  • 50,000
  • 100,000

Design Options

Glass Options
  • Opaque White
  • Opaque Black
  • Mirrored Gray
  • Mirrored Bronze
  • Translucent Black

Weather Stripping
  • Jamb seals
  • Header seals

Powder Coat Track Options
  • White
  • Black

Colors

Anodized Finish
Bronze Black

Powder Coat Finish
White Bronze Black



*Online color swatches are only digital reproductions of actual standards and will vary in appearance due to differences in monitor and video card output. These digital representations should not be used to finalize color selection(s).

Actual physical representation may vary slightly in color.
