Features/Options

TradeMark Features and Options

Raynor TradeMark steel pan residential garage doors have the following features and options.

Hardware: Track formed from strong galvanized steel, paired with durable, long-wearing nylon rollers ensure smooth, quiet operation.
Section Joints: Strong, roll-formed tongue-and-groove meeting rails seal out wind, rain, and snow, keeping your garage dry and secure.
Insulation: The optional energy-saving core of polystyrene insulation provides added comfort and helps keep your TradeMark garage door quieter.
Raynor Wind Load Secure: TradeMark doors are available in a wide variety of wind load pressure ratings to meet your local wind codes.
Commercial TradeMark Available: TradeMark is also available in commercial sizes, up to 16’ high, and comes with our Raynor commercial hardware.

Colors

Pick Your Garage Door Color

Start creating a beautiful, customized Raynor TradeMark garage door design that fits your style by selecting from one of our many color options. Deep, distinct embossing creates a sharp and detailed-looking garage door front. Classic, or contemporary, Raynor garage doors look high definition.

Standard Solid Colors


White	Almond	Sandstone	Bronze	Brown

>>Not all colors are available on all embossments. Contact your local Raynor Authorized Dealer for a complete listing of colors available by embossment.

>>Colors displayed on monitors, mobile devices, and printed materials will vary from the actual steel color. Contact your local Raynor Authorized Dealer for color samples.

Optional Post Paint Process*

Raynor’s ColorWave™ features Sherwin-Williams® next-generation post paint system for your garage door. With 1,500 colors to choose from, home and business owners can couple this elite paint system with state-of-the-art Raynor manufacturing to craft the perfect look for their home or project.

* Not all colors are available in solar reflective paint, colors that are not available as solar reflective cannot be used on polyurethane doors.

Panels

Pick Your Garage Door Panel

Raynor TradeMark offers three distinctly different panel options to help give your home a custom and unique look.


Raised Colonial	Raised Ranch	Recessed Colonial Grooved

Hardware

Pick Your Decorative Hardware

The optional decorative hardware black matte powder coated straps and handles are designed to appear hand-forged, adding a historically accurate dimensional quality to your TradeMark garage door. Choose from a variety of design options.

Decorative Hardware Options

Handles

Straps

Plastic Decorative Hardware Kits

Windows

Decorative Windows

Our beautiful window designs put the finishing touch on your Raynor TradeMark garage door. Choose from clear, obscure glass.

Glass Options

Snap-In Styles

Snap-in window designs add charm to any home. Choose from a variety of styles.

Colonial


Clear Colonial	Waterton Colonial	Cascade Colonial

Prairie Colonial	Stockton Colonial	Arched Stockton Ranch

Stockbridge Ranch	Berkshire	Breckenridge

Ranch


Clear Ranch	Waterton Ranch	Cascade Ranch

Praire Ranch	Stockton Ranch	Arched Stockbridge Ranch

Details/Literature

Product Details

Max Door Width	20’2” (20’2” in commercial sizes)
Max Door Height	10’0” (16’0” in commercial sizes)
Construction	1 or 2-layer
Section Thickness	2″
Material	Hot-Dipped Galvanized Steel; 24-gauge
Surface Texture	Embossed Woodgrain
Insulation	Expanded Polystyrene (optional)
Tested U-Factor	N/A
Calculated R-Value	6.6
Thermal Break	No
Section Joint Seal	No
Section Joint Type	Tongue-in-Groove
Door Designs	Raised Colonial, Raised Ranch, Recessed Colonial Grooved
Colors	White,Almond,Bronze,Brown,Sandstone,ColorWave™
Glass	Clear, Obscure
Decorative Windows	Various snap-in designs in colonial or ranch size
Track & Door Hardware	Galvanized
Wind Load Systems	FBC: Yes TDI: Yes HVHZ: Yes
Single Family Residential Warranty: Limitations and Exclusions May Apply	Sections: Limited Lifetime Galvanized Track & Hardware: 6 years Springs: 3 years Windows: 3 years Climate Seal: 1 year Windoad Doors: 3 years ColorWave™: 5 years

Product Literature

Specs/Drawing

Specifications

Select a link below to download Raynor Commercial TradeMark specifications.

	Word	PDF
Commercial TradeMark & BuildMark	DOCX	PDF
Full Sectional Product Line Specs	DOCX	PDF

Warranty

TradeMark Residential Garage Door Warranty

Door Sections:

Single Family Residential: Raynor® warrants the door sections against defects in material and workmanship, and deterioration due to rust-through for as long as the original purchaser owns the home. Window components are warranted against defects in material and workmanship for three (3) years from date of delivery to the original purchaser. Climate seal is warranted against defects in material and workmanship for one (1) year from date of delivery to the original purchaser.

All Other Residential (including installation on rental properties, homes owned by common condominiums associations or similar organizations):
Raynor® warrants the door sections against defects in material and workmanship, and deterioration due to rust-through for three (3) years from date of delivery to the original purchaser. Window components are warranted against defects in material and workmanship for three (3) years from date of delivery to the original purchaser. Climate seal is warranted against defects in material and workmanship for one (1) year from date of delivery to original purchaser.

Hardware and Springs:

Single Family Residential: Raynor® warrants all hardware components against defects in material and workmanship for six (6) years and springs for three (3) years from date of delivery to the original purchaser. Raynor wind load systems are warranted against defects in material and workmanship for three (3) years from date of delivery to the original purchaser.

All Other Residential (including installation on rental properties, homes owned by common condominiums associations or similar organizations):
Raynor® warrants all hardware and spring components against defects in material and workmanship for one (1) year from date of delivery to the original purchaser.

ColorWave™ Paint System
Raynor provides a five-year warranty for the ColorWave Paint System (exterior only) against chipping, cracking, and peeling (loss of adhesion) from the date of delivery to the original purchaser. This warranty covers defects in materials and workmanship under normal use and proper maintenance. Please note that fading, as well as chipping, cracking, or peeling caused by dents or scratches, are not included in this coverage. Additionally, for doors made with polyurethane insulation, a solar reflective paint formulation is required to maintain the warranty. Ordering a color that does not meet this requirement will void the warranty for the ColorWave Paint System. Field applied paint is not covered by this warranty. This warranty applies only to the original purchaser and may be subject to inspection before approval of any claim.

Warranty Limitations and Exclusions:

Under the terms of this limited warranty, for any door components that are found to be defective upon inspection by authorized Raynor personnel, Raynor will, at its option, repair or replace the defective door components. Labor charges for the installation or repairs shall be the responsibility of the consumer and must be performed by an authorized Raynor dealer.

This limited warranty extends only to the original purchaser, provided the door is installed in his/her place of residence. This limited warranty is not transferable. This limited warranty applies to residential property only and is not valid on commercial applications or commercial use from a private residence.

This limited warranty does not apply to automated parking control systems for multiple-tenant parking applications.

This limited warranty does not apply to black, charcoal, slate, and iron ore steel colors used on Raynor Aspen Series, Commercial Aspen Series, Country Manor, and RockCreeke doors when installed in areas experiencing extreme heat for prolonged periods of time. The result of these environmental conditions can elicit a failure of the polyurethane core of the door. The warranty also excludes doors which have been field painted where the paint does not include a solar reflective additive.

This limited warranty does not apply to any damage or deterioration to the door caused by abuse, negligence, missing components, accidents, use of pressure washers, dents or scratches. Shavings from trolley rails not properly removed and cleaned from the exterior door surface causing rust are not covered by this warranty. Failure to provide proper maintenance voids this limited warranty. Field applied paint failure is not covered by this limited warranty. Refer to the Care and Maintenance Instructions and Painting Instructions.

This limited warranty does not apply to damage caused by fire, an act of God, accident, vandalism or graffiti. Damage or deterioration caused by saltwater coastal areas (within two miles), hazardous or corrosive chemicals and fumes including, but not limited to, alkaline, acids, muriatic acids, road salt or salt environments, harsh cleaning agents, and fertilizers is not covered by this limited warranty.

This limited warranty does not apply to building damage caused by moisture infiltration through or around the door. A garage door system is water resistant, but not waterproof. When a garage door system is properly assembled, installed, and maintained the risk of significant water infiltration is low.

Raynor will not be responsible for paint rub on installed doors in any openings. Raynor shall not be liable for any consequential or incidental damages.

ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY EXPRESSLY EXCLUDED.

Some states do not allow the exclusion or limitation of consequential or incidental damages, so the above limitation or exclusion may not apply to you.

Claims for defects in material and workmanship covered by this warranty shall be made in writing with proof of purchase and photographs of the product in question to the dealer from whom the product was purchased or call Raynor at 1-800-4-RAYNOR within the warranty period. Raynor may choose to have the product returned for inspection.

This limited warranty gives you specific legal rights. You may also have other rights, which vary from state to state.

Register Your Warranty

Your registration enforces your warranty coverage and will keep you up to date on product information and offers. Register your Raynor TradeMark warranty here.
